Yamamoto Washer Extractor

Perfect for the smaller laundry operator or business needing a compact washer with a big heart . The WN223D is a delight to operate and own, experience ultimate Japanese reliability with the WN223D soft-mounted, high spin washer/extractor.. An extra-large door opening speeds loading and unloading, The WN223D model is available with your choice of either steam heating or electric booster heating or Both .Up to 120 wash program choice available ,Clean cycle selections and indicators let the operator know what stage the cycle is at all times. Touch screen control, fully balanced drum , high quality Stainless Steel materials, Amazing wash results for the experienced operator. Staff will enjoy the near zero out of balance faults associated with other similar capacity washers. Easy to use controller, extremely easy to program or adjust existing programs. Wash programs may be password protected if needed. The WN223D is absolute Japanese perfection You won't be dissapaointed !

WN223D

  • Touch Screen control
  • Microprocessor Control
  • Easy Access Servicing
  • Soft mount
  • Stainless Steel Construction
  • Japanese Perfection
  • Variable speed Drive
  • Direct Drive
  • Super Heavy Duty Bearings
  • Extra Large Door and Handle
  • Auto or manual Soap injection
  • Outstanding Warranty
  • 10 water levels settings

Extract RPM
800RPM

Capacity
28kg capacity

Cylinder Type
Stainless Steel

Suspension
Soft Mount

Controller Type
Touch Screen fully programmable

Technical Specifications
Drum - Diameter x Depth 890mm-x-461mm
Motor power (kw) 5
Drum - Volume 286 ltrL
Electric Heat (kw) 6
Hot and cold water inlet diameter (mm) 1 inch
Power Capacity 3-phase AC415V 30A
Dimensions (mm) L1233xD1284xH1700
Weight (kg) 850KG
